Classical differential scanning calorimetry conducts thermal analysis by controlling temperature programs to observe heat effects. This method is extensively utilized across various material and chemistry research endeavors, including process optimization, quality control, and failure analysis. Through DSC, one can investigate inorganic material phase transitions, polymer melt crystallization solid/liquid ratios, drug polymorphs, food items like grease, and more.
Heat type differential scanning calorimeter repeatability, accuracy, particularly suitable for precise measurements of the specific heat.
Independent research and development of the constant temperature controller; Constant temperature gas chromatography and mass spectrometry connected head; Constant temperature.
Machine integration, and the furnace temperature control unit volume as a whole, to reduce signal loss and interference.
Two perfect atmosphere control system that uses mass flow controllers.
Instrument is equipped with standard materials, the user can correct the temperature ranges of their own, to reduce the error of the instrument.
Intelligent software design, full automatic drawing instrument, the software can achieve a variety of data processing, such as enthalpy calculations, the glass transition temperature, the oxidation induction period and the melting point of the crystalline material and the like.
DSC instrument can automatically generate test reports and oxidation induction period.
Temperature data | |||
Temperature range | HSC-1: RT～680℃(optional 1150℃) HSC-2: -30～680℃(mechanical refrigeration) HSC-3: -100～680℃(manual feed nitrogen) HSC-4: -100～680℃(automatic feed nitrogen) | ||
Temperature accuracy | ±0.1 | ||
Heating rate | 0.1℃/min～100℃/min | ||
Repeatability | ±0.1℃ | ||
DSC data | |||
Temperature control | Heating thermostat(the program automatically) | Gas flow | 10～200mL/min |
Measurement range | ±500mw | Minimum resolution | ±0.1μw |
Sample pan | |||
Ceramic 0.06mL Aluminum 0.06mL Platinum 0.06mL | Sealed aluminum crucible 30 μ L Sealed stainless steel high-pressure crucible 30 μ L | ||
Temperature correction | Baseline correction intelligent freely selectable With standard characteristics(indium,tin,lead,zinc,alumi num),the user can correct the temperature | ||
